Automatic Barbed Wire Making Machine

Name: Automatic Barbed Wire Making Machine
Brand: ASHU ENTERPRISES
Price: 150000 INR
Availability: InStock

Price 150000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Automatic Barbed Wire Making Machine Specification

Product Type
Automatic Barbed Wire Making Machine

Wire Material
Galvanized Iron, Mild Steel

Inlet Diameter
1.6 mm 3.0 mm

Outlet Diameter
1.5 mm 2.8 mm

Voltage
380 V

Power
2.2 kW 3.7 kW

Dimension (L*W*H)
2400 mm x 1000 mm x 1200 mm

Usage
Barbed wire manufacturing

Weight
1000 kg

Color
Blue / Green / As per order

Automatic Barbed Wire Making Machine Trade Information

Minimum Order Quantity
1 Unit

FOB Port
BATALA

Supply Ability
100 Units, , Per Month

Delivery Time
3-4 Days

Packaging Details
WOODEN PACKING

Main Domestic Market
All India

About Automatic Barbed Wire Making Machine

MOTOR 5 HP 1440 RPM (CROMPTON), STARTER, V-BELTS ANDPULLEY.

ACCESSORIES TO BE SUPPLIED:-

TOOL SET 1 NOS

PRODUCTION CAPACITY:-

12 X 12 GAUGE 600 KGS/8 HRS

13 X 13 GAUGE 550 KGS/8 HRS

14 X 14 GAUGE 500 KGS/8 HRS

Efficient Barbed Wire Production

Designed for continuous operation, the machine produces between 35 and 50 kg of barbed wire per hour, streamlining manufacturing workflows. Its automation minimizes manual intervention, requiring just one operator per shift, while the belt and gear main drive ensures consistent, reliable performance. The adjustable barb spacing allows customization to specific fencing needs.

Flexible Operation with Advanced Control

Accommodating both single and three-phase power supplies, the machine features a semi-automatic control panel for precise operational settings. The noise level remains low, allowing for use in various environments. With options for strand twist and customizable color, it matches different customer requirements and facility aesthetics.

Robust Build and Versatile Application

Manufactured with high-grade materials, the machine handles galvanized iron and mild steel wires, ensuring longevity and rust resistance in final products. Its compact dimensions and moderate weight enable easy installation across manufacturing plants, and it's ideal for exporters, importers, manufacturers, service providers, suppliers, and traders.

FAQ's of Automatic Barbed Wire Making Machine:

Q: How does the Automatic Barbed Wire Making Machine operate?

A: The machine uses a belt and gear-driven system, with a semi-automatic control panel for managing production. It requires one operator, making it highly efficient and easy to run throughout an 8-hour shift.

Q: What types of wire materials can be processed with this machine?

A: The machine is compatible with galvanized iron and mild steel wire, supporting inlet diameters from 1.6 mm to 3.0 mm and output diameters from 1.5 mm to 2.8 mm, ensuring versatility for various fencing projects.

Q: When is the best time to use this machine for barbed wire manufacturing?

A: It is ideal for both small- and large-scale barbed wire manufacturing, operating reliably during routine production cycles, and is especially beneficial for facilities targeting high daily outputs of 400-600 kg.

Q: Where can the Automatic Barbed Wire Making Machine be installed?

A: Due to its compact design (2400 mm x 1000 mm x 1200 mm) and low noise level, the machine can be installed in most indoor manufacturing settings, including factories, workshops, or dedicated production units in India.

Q: What is the process involved in making barbed wire with this machine?

A: Wire is fed into the machine, twisted using single or double twist settings, and barbs are formed at adjustable spacings between 3 to 6 inches. The finished barbed wire is output as two strands, ready for winding or packaging.

Q: How is this machine beneficial for barbed wire production businesses?

A: It increases production capacity, reduces labor costs, and delivers consistent output quality. The automation and adjustable features contribute to efficiency and help meet varied customer demands while minimizing downtime.

Q: What are the usage guidelines for operating this machine safely and efficiently?

A: Operators should ensure the power supply matches the motor type (single/three-phase), monitor the semi-automatic control panel, and regularly check wire feed alignment and lubrication to maintain smooth operation and product quality.
